BLANKET
Excellent insulating properties; low thermal conductivity, excellent thermal shock resistance, low heat storage capacity, inorganic (smoke free). Used in Furnace kiln, reformer and boiler lining, Laboratory ovens, Furnace door lining and seals, Furnace repair, Annealing furnace linings, Investment casting mold wrap, Stress – relieving blankets, Reusable steam and gas turbine insulation, Expansion joints packing, High temperature gaskets, Fire protection, Acoustical service.
Working Temp (F) DATA MSDS
KAOWOOL, KAOWOOL RT, CERABLANKET, CERACHROME, CERACHEM 2000-2600
SUPERWOOL 607, PLUS, 607 HT 2012-2372
BOARD
Strong, thin, durable ceramic fiber based boards with a variety of high-temperature applications. Their use should be considered whenever there is a need for a thin, durable board with excellent insulating characteristics such as Furnace and kiln hot face linings, Combustion chambers for boilers and heaters, Hot gas duct, flue and chimney liners, Appliance and heat processing insulation, Heat Shields.
Working Temp (F) DATA MSDS
KAOWOOL M, PM, HP, HD, A, HS, HS45, HT, 2600, 80, 3000 2000-2950
KAOWOOL Millboard 2000-2700
SUPERWOOL 607, 607 PM, 607 HT, I607, Alfibon 607 1832-2150
BULK
Thermal Ceramics bulk products are produced by varying composition, fiber length, compressed density, fiber content, fiber diameter, and lubricity to serve a wide range of customer needs. Expansion joints construction, Low mass kiln car construction, Tube seal fabrication, Thermal and acoustical insulation, Filtration media, Reinforcement for plastic and resins, Filler in resins and paint.
Working Temp (F) DATA MSDS
KAOWOOL, KAOWOOL HP, CERAFIBER, CERACHEM, CERACHROME, SAFFIL 2000-2800
SUPERWOOL 607, PLUS, 607 HT 1832-2012
PAPERS
High-performance paper products for thermal, acoustical, or filtration management. Good resistance to tearing, high flexibility, resistant to thermal shock and have very low thermal conductivity and low thermal mass.
Working Temp (F) DATA MSDS
KAOWOOL 500, 700, 900, 2000, 2600, 3000 2150-3000
SUPERWOOL 607, 607 HT 1832-2372
LYTHERM 550-L 2300
LYTHERM 970-L 2300
LYTHERM 1530-L, 1535-L 2300
LYTHERM LDF 1400
LYTHERM ROLLBOARD 2300
FELTS
Ceramic felt exhibits excellent strength, has good flexibility and is pleasant to handle, cuts cleanly and is ideally suited for the manufacture of the most intricate die-cut shapes and gaskets even in thin sections. It is available in roll form which permits maximum material utilization offering improved flexibility to the die-cutter.
Working Temp (F) DATA MSDS
K Shield 2300
Cerafelt, Cerachrome 2300
BRICK
Insulating Firebrick (IFB) operate in temperatures up to 3250°F (1787°C). In addition, a line of high alumina (90%+) dense firebrick, SR® is engineered to handle very difficult applications. These high purity bricks have excellent load-bearing strength at temperatures above 3000°F (1649°C), and provide good thermal shock resistance.
Working Temp (F) DATA MSDS
K-23, TC-23, IFB-23, K-25 2300-2500
K-26, TJM-26, TJM-28, JM 28, JM-30 2600-3000
CASTABLES
Monolithic products provides a wide range of innovative solutions for heat-intensive challenges. Available in different formulations, densities, and installation methods, monolithics can be used as primary or secondary insulation, for repair, or for specialty applications. A lining may be installed using a single material or can be a complex selection depending on the environment/operation of the lined structure. Specific grades have been developed for high temperature insulation, metal contact, slag resistance, abrasion resistance or thermal shock resistance.
Working Temp (F) DATA MSDS
Kaocast, Kaocrete 3000
Kaolite 1600-1800 1600-1800
Kaolite 2800-3300 2800-3300
MORTAR, CEMENT, COATINGS
Fiber based insulation materials available in coatings and cements. Manufactured specifically to aid in efficient furnace, kiln and boiler operation, these products eliminate hot spots, provide superior maintenance solutions, and make insulation installation quick and easy.
Working Temp (F) DATA MSDS
Mortars Smoothset, Airset, High Temp 2850-3000
Cerakote, Kaowool B Cement 2150-2200
Rigidizer
Kaowool Sealcote HT 2500
Superwool Sealcote HT 2600
PUMPABLES, MOLDABLES
Fiber based insulation materials available in pumpables, moldables. Manufactured specifically to aid in efficient furnace, kiln and boiler operation, these products eliminate hot spots, provide superior maintenance solutions, and make insulation installation quick and easy.
Working Temp (F) DATA MSDS
Kaowool Pumpable 1900-2800
Superwool Pumpable 1900
Kaowool Moldable 1800-2000
Superwool Moldable 2000
MODULES
Pyro-Bloc modules are manufactured from a monolithic ceramic fiber. Pyro-Bloc modules combine the insulating material advantages of ceramic fiber with rapid furnace installation. These modules are lightweight, have low heat storage and provide durable service.
Working Temp (F) DATA MSDS
Pyro-Bloc Y 2200-2500
Pyro-Bloc M 2200-2500
Pyro-Fold, Uniblock, Z-Bloc 2200-2500
Superwool Pyro-Fold, Pyro-Stack 1832-2102
